Specifications
Product Parameters
Model-specific data below is maintained from the internal specification sheet. Final quotation can still be confirmed by selected model, order quantity, and buyer market requirements.
A listed withstand-voltage value is not a working-voltage rating or permission for live electrical work. Before electrical use, request documentation for the exact ladder model and confirm the test conditions, equipment condition and permitted use. A material report alone does not establish whole-ladder electrical protection.
| Item No. | Step | Withstand Voltage | Pedal Spacing | Open Height | Weight | Packing Size | Thickness | Max Load | Packing |
|---|---|---|---|---|---|---|---|---|---|
| SSFW802-3 | 2 | 35KV | 30CM | 87CM | 4.8KG | 96×39×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-4 | 3 | 35KV | 30CM | 116CM | 5.8KG | 126×41×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-5 | 4 | 35KV | 30CM | 145CM | 7.4KG | 156×43×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-6 | 5 | 35KV | 30CM | 172CM | 8.2KG | 186×45×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-7 | 6 | 35KV | 30CM | 203CM | 9.4KG | 216×47×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-8 | 7 | 35KV | 30CM | 233CM | 10.6KG | 246×49×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-9 | 8 | 35KV | 30CM | 261CM | 12KG | 276×51×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSFW802-10 | 9 | 35KV | 30CM | 290CM | 13.4KG | 306×53×13CM | 3.0MM | 150KG | Cover&Shrink |
