Specifications
Product Parameters
Model-specific data below is maintained from the internal specification sheet. Final quotation can still be confirmed by selected model, order quantity, and buyer market requirements.
A listed withstand-voltage value is not a working-voltage rating or permission for live electrical work. Before electrical use, request documentation for the exact ladder model and confirm the test conditions, equipment condition and permitted use. A material report alone does not establish whole-ladder electrical protection.
| Item No. | Step | Withstand Voltage | Pedal Spacing | Open Height | Weight | Packing Size | Thickness | Max Load | Packing |
|---|---|---|---|---|---|---|---|---|---|
| SSF805-4 | 4 | 35KV | 30CM | 115CM | 7.4KG | 123×40×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-5 | 5 | 35KV | 30CM | 143CM | 9.5KG | 153×42×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-6 | 6 | 35KV | 30CM | 170CM | 10.8KG | 183×44×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-7 | 7 | 35KV | 30CM | 201CM | 12.6KG | 213×46×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-8 | 8 | 35KV | 30CM | 230CM | 14.2KG | 243×48×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-9 | 9 | 35KV | 30CM | 260CM | 16KG | 273×50×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-10 | 10 | 35KV | 30CM | 290CM | 18KG | 303×52×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-12 | 12 | 35KV | 30CM | 342CM | 22.4KG | 363×54×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-14 | 14 | 35KV | 30CM | 400CM | 26.4KG | 423×56×20CM | 3.0MM | 150KG | Cover&Shrink |
| SSF805-16 | 16 | 35KV | 30CM | 456CM | 31.4KG | 483×58×20CM | 3.0MM | 150KG | Cover&Shrink |
