Product Parameters
| Item No. | Step | Withstand Voltage | Pedal Spacing | Open Height | Weight | Packing Size | Thickness | Max Load | Packing |
|---|---|---|---|---|---|---|---|---|---|
| SSF810-3 | 3 | 35KV | 30CM | 144CM | 9.8KG | 158×50×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSF810-4 | 4 | 35KV | 30CM | 174CM | 10.8KG | 188×52×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSF810-5 | 5 | 35KV | 30CM | 204CM | 13KG | 218×54×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSF810-6 | 6 | 35KV | 30CM | 234CM | 14KG | 248×56×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSF810-7 | 7 | 35KV | 30CM | 264CM | 15.4KG | 278×58×13CM | 3.0MM | 150KG | Cover&Shrink |
| SSF810-8 | 8 | 35KV | 30CM | 294CM | 16.4KG | 308×60×13CM | 3.0MM | 150KG | Cover&Shrink |
Specification notes
The model-specific data in the specification table comes from the internal specification sheet. The final quotation is confirmed after reviewing the selected model, order quantity and destination-market requirements.
Published weight; confirm the net/gross basis for freight planning.
SSLADDERS guarantees a 35 kV withstand-voltage specification for all fiberglass ladders in our range, covered by a unified test report. Request the report for your selected models and review its recorded test conditions. A listed withstand-voltage value is not a working-voltage rating or permission for live electrical work. Before electrical use, request documentation for the exact ladder model and confirm the test conditions, equipment condition and permitted use. A material report alone does not establish whole-ladder electrical protection.
