Product Parameters
| Item No. | Step | Pedal Spacing | Open Height | Weight | Packing Size | Thickness | Max Load | Packing |
|---|---|---|---|---|---|---|---|---|
| SS812-3 | 3 | 25CM | 99CM | 3.7KG | 99×40×6CM | 1.2MM | 150KG | Shrink |
| SS812-4 | 4 | 25CM | 123CM | 5.8KG | 123×40×6CM | 1.2MM | 150KG | Shrink |
| SS812-5 | 5 | 25CM | 147CM | 7.9KG | 147×40×6CM | 1.2MM | 150KG | Shrink |
| SS812-6 | 6 | 25CM | 171CM | 9.9KG | 171×40×6CM | 1.2MM | 150KG | Shrink |
| SS812-7 | 7 | 25CM | 195CM | 12.2KG | 195×40×6CM | 1.2MM | 150KG | Shrink |
Specification notes
The model-specific data in the specification table comes from the internal specification sheet. The final quotation is confirmed after reviewing the selected model, order quantity and destination-market requirements.
Published weight; confirm the net/gross basis for freight planning.
Before ordering, confirm the exact model, current photographs, dimensions, load rating and packing details with us. Request the supporting specification and any required model-specific test documents; the product image alone does not verify these values.
